TANGO Original Universal Transponder Key Programmer Basic Device From Scorpio LK

TANGO programmer is intended for programming transponders, which are a part of automobile immobilizing systems unlike the previous model the Gambit.

The new model from Scorpio TANGO is the two-band device that has allowed the addition of the list of supported transponders with firm Texas Instruments products (Tiris ©).

TANGO Key Programmer is the next generation of transponder programmers which is continuously developed to cover, read, and write the latest transponders used in the newest vehicle immobilizer technologies.

A new function for reading the Kilometers, VIN, and transponder type for all BMW keys has been added to the BMW software module.

Please Note After generating a new transponder with TANGO Programmer, you do not need any additional diagnostic equipment to program the generated transponder to the car.

It will start the car directly, even on the new FIAT CODE 2 system, which is also used in PSA Group vehicles.

You only have to write the new file back into the immobilizer system.

The ever-expanding list of key makers currently totals over 1116 (Over 580 are included with basic software)

Update 1.108 of the TANGO programmer introduces brand new functionality for work with Toyota/Lexus vehicles equipped with SmartKey Systems via OBD. The framework is implemented in TANGO Toyota+ software.

The main objective of the software is to allow the addition of smart keys in the " all keys lost; situation by creating an emulator that allows getting permission to register new keys via diagnostic equipment.

Scorpio TANGO Transponder Programmer Highlights

Cloning of Toyota / Lexus Smart keys on SLK-01, SLK-02, SLK-03/03E, SLK-04/04E, SLK-05/05E, SLK-07E emulators

Subaru Image Generation Page1 14, 17

TANGOPlus Subaru Smart Key (Page1 F1, F3) Systems OBD framework

Toyota-H Immobilizer All Keys Lost solution (Gen1 MCU 11910 & Gen2 MCU 12xxx) - TANGO + Barracuda (all markets)

Toyota-H Immobilizer All Keys Lost solution (Gen1 MCU 11910) - SLK-06 (all markets)

Cloning of Toyota H-key [Blade](128bit) on LKP-04

Toyota/Lexus Smart Key Systems OBD Framework

Toyota G Immobilizers OBD Reset & Add Key (including EU type)

Toyota/Lexus H Keys Image Generation Page1 39, 59, 5A, 99, 3A, 7A on TRPWS21 transponder

Toyota/Lexus G Keys Image Generation and Cloning Page1 19,36,56,96,37,57 on LKP-02, CN5

Toyota/Lexus/Subaru SmartKey Reset (40/80/128bit)

FREE Off-line Full Copy of TIRIS DST (ID60-70) onto TPX2,EH2,CN2,CN5,LKP-02

FREE Image generator ID70 on ID4D

Image generator ID67/68 on ID4D

Total FREE production of TP22, TP23, TP24, TP25

Free write Component Security 7 bytes Tool (Megamos48)

In-depth Manual and Technical Support Provided

Searching of the 7th byte by existing car's key(Megamos48)

TANGO Key Programmer Features

TANGO auto key programmer has over 1142 Key Makers, 793 included with essential TANGO software

Toyota Smart key all keys lost programming Via OBD II Using SLK Emulators (extra adapters & software’s are required) TANGO SLK emulator set

Toyota-H Immobilizer All Keys Lost solution (all markets) with the help of Barracuda key programmer

TANGO cloning Toyota H-key [Blade](128bit) on LKP-04

Toyota dump editor to pair Smart key ECU with ID CODE ECU (Payable software)

Toyota G immobilizers OBD Reset & Add Key (including EU type) TANGO G software is required & TANGO G cable

Toyota/Lexus H Keys Image Generation Page1 39, 59, 5A, 99, 3A, 7A on TRPWS21 transponder chip

Free Transponder production & cloning for many models

Supporting key & smart key programming for Vehicles, Trucks, and motorbikes

Toyota/Lexus G Keys Image Generation and Cloning Page1 19,36,56,96,37,57 on LKP-02 transponder chip

Toyota, Lexus & Subaru Smart key reset (Payable software)

Full FREE production of Seat TP22 transponder chip, Volkswagen TP23 transponder chip, Skoda TP24 transponder chip, Audi TP25 transponder chip

Free write VAG Component Security 7 bytes Tool (Megamos 48)

TANGO unlocks used remotes for some types of Chrysler remote key unlocking, Honda remote key unlocking, Suzuki transponder key unlocking, Kia transponder key unlocking, Hyundai transponder key unlocking & VAZ remote key unlocking

TANGO reads the Kilometers, VIN, and transponder type for many key types

Free Off-line Full Copy of TIRIS DST (ID60-70) onto TPX2 transponder chip, EH2 transponder chip, CN2, CN5 transponder chip, LKP-02 transponder chip

TANGO-free Image generator ID70 on ID4D

TANGO unlocks Audi 8E Megamos chip via Audi EZS Dump (Payable software)

TANGO searching of the VAG 7th byte by existing car's key (Megamos 48)

TANGO Toyota Techstream passcode calculation (Payable software)

TANGO AD100 out-in code 8-digit calculation

Free TANGO software updates

System Requirements:

TANGO programmer

J2534 PassThru compliant OBD cable

SLK emulator corresponding to system type

Toyota maker software activation

SLK-0x software activation

Toyota TIS Techstream

Windows XP/7/8/10 PC/Laptop

The product is in the working-out stages, therefore the list of the supported transponders will be developed later.

For the present moment, TANGO has the following built-in makers and functions

The device has an ergonomic design with high mechanical characteristics of the IP65 class according to the DIN EN 60529 standard.

The device has the following dimensions:

Length 160 mm

Width 80 mm

Height 50 / 30 mm

The device enclosure is made of 3mm ABS plastics with a rubber shock-proof damping seal which simultaneously is a decor element.

The seal also prevents the device from sliding on a work table surface.

Also as well as the Gambit, the device derives the power from USB and does not demand a connection to an external power source.

The difference is the use of drivers of other types that allow for avoiding conflicts with other devices working through virtual ports USB2.0/3.0

Unlike the Gambit, the device has a wide slot for keys of any size and two small holes of various depths for transponders of any size.

LED indication unlike Gambit is taken out on the upper cover of the case which is a solution more convenient in use.

The program interface has a modern intuitive design favorably differing from the interface of Gambit.

Meeting modern requirements, TANGO supports OS Vista which was not realized in Gambit.

Supported versions of Windows:

Win 98

X

Vista

Win 7

Win 8/8.1

Win 10

<table> <thead> <tr> <th>Chip</th> <th>Features</th> <th>Copy</th> </tr> </thead> <tbody> <tr><td colspan="3"><b>ATMEL</b></td></tr> <tr><td>Temic 11</td><td>Read</td><td>TK5551M, T5</td></tr> <tr><td>Temic 12</td><td>Read</td><td>TK5551M, T5</td></tr> <tr><td>Temic 8C</td><td>Read IDE, Authentication</td><td>TK5561A</td></tr> <tr><td>TK5551M</td><td>Read, Write</td><td>-</td></tr> <tr><td>TK5561A</td><td>Read, Write</td><td>-</td></tr> <tr><td colspan="3"><b>ELMOS</b></td></tr> <tr><td>ELMOS for BMW</td><td>Read, Write, Battery charging</td><td>N/A</td></tr> <tr><td colspan="3"><b>EM Microelectronic-Marin</b></td></tr> <tr><td>Megamos 13</td><td>Read, Write</td><td>T5</td></tr> <tr><td>Megamos 48</td><td>Read, Write, PIN function, Authentication</td><td>N/A</td></tr> <tr><td>Megamos 8E</td><td>Read, Write</td><td>N/A</td></tr> <tr><td colspan="3"><b>JMA</b></td></tr> <tr><td>TPX1</td><td>Read, Write</td><td>-</td></tr> <tr><td>TPX2</td><td>Read, Write</td><td>-</td></tr> <tr><td colspan="3"><b>Philips / NXP</b></td></tr> <tr><td>PIT (PCF7930/31)</td><td>Read, Write</td><td>-</td></tr> <tr><td>SECT (PCF7935)</td><td>Read, Write, Crypto calc.</td><td>-</td></tr> <tr><td>HITAG2</td><td>Password/Crypto mode, Auto swap User/Remote</td><td>-</td></tr> <tr><td>HITAG2+EE</td><td>Crypto mode, EEPROM access (R/W)</td><td>-</td></tr> <tr><td>HITAG2 Extended</td><td>Password/Crypto mode, EEPROM access (R/W)</td><td>-</td></tr> <tr><td>HITAG3</td><td>Read IDE, Authentication</td><td>-</td></tr> <tr><td>HITAG Pro</td><td>Read IDE, Authentication, EEPROM access (R/W)</td><td>-</td></tr> <tr><td colspan="3"><b>Custom HITAG-Based</b></td></tr> <tr><td>HITAG2 for BMW</td><td>Password/Crypto mode, EEPROM access (R/W), BMW Remote data</td><td>-</td></tr> <tr><td>HITAG for VAG</td><td>Read IDE, EEPROM access in Open mode</td><td>-</td></tr> <tr><td colspan="3"><b>LKP</b></td></tr> <tr><td>LKP-02</td><td>Read, Write</td><td>-</td></tr> <tr><td>LKP-04</td><td>Read, Write</td><td>-</td></tr> <tr><td colspan="3"><b>SAAB</b></td></tr> <tr><td>Saab custom</td><td>Read</td><td>TK5551M, T5</td></tr> <tr><td colspan="3"><b>SILCA</b></td></tr> <tr><td>EH2</td><td>Read, Write, Reset</td><td>-</td></tr> <tr><td colspan="3"><b>Scorpio-LK</b></td></tr> <tr><td>SLK-01</td><td>Read, Write</td><td>-</td></tr> <tr><td>SLK-02</td><td>Read, Write</td><td>-</td></tr> <tr><td>SLK-03</td><td>Read, Write</td><td>-</td></tr> <tr><td>SLK-04</td><td>Read, Write</td><td>-</td></tr> <tr><td>SLK-05</td><td>Read, Write</td><td>-</td></tr> <tr><td colspan="3"><b>Sokymat</b></td></tr> <tr><td>T5</td><td>Read, Write</td><td>-</td></tr> <tr><td colspan="3"><b>TEXAS</b></td></tr> <tr><td>TIRIS 4C</td><td>Read</td><td>-</td></tr> <tr><td>TIRIS DST 4D</td><td>Read, Write, Crypto calc.</td><td>-</td></tr> <tr><td>TIRIS DST 4E</td><td>Read, Write, Crypto calc.</td><td>-</td></tr> <tr><td>TIRIS DST+</td><td>Read, Write, Crypto calc.</td><td>-</td></tr> <tr><td>TIRIS DST80</td><td>Read, Write</td><td>-</td></tr> <tr><td>Texas TRPWS21</td><td>Read, Write</td><td>-</td></tr> </tbody> </table>
