CSH-002 Mini Vertical Milling Key Cutting Machine Key Duplicator Support Car, Motorcycle and Residential Keys:
The CSH-002 Mini Vertical Key Cutting Machine is a versatile and portable key duplicator used for cutting various types of keys including car, motorcycle and residential keys. It supports both internal and external milling with high precision, with a milling accuracy of 0.02 mm. The machine can be powered by both AC and DC, making it convenient for outdoor use via a car cigarette lighter or battery charger.
CSH-002 Mini Vertical Key Cutting Machine Features:
- CSH-002 capable of both external milling and internal milling, with small body size and wide range of usage, making all kinds of keys such as inside slots, hole-punches, civil keys, as well as car keys and motorcycle keys.
- The power supply mode is flexible, both AC and DC can be applied, car cigarette lighter, battery charger can be directly used for power supply, convenient for your outdoor work.
- The accuracy of the machine is set within 0.02mm, and the multifunctional patented clamps make it fastly, gently and accurately.
- The spindle and guide pins are made of hardened high-speed steel to ensure the screw not slipping.
- It applies electronic tool-setting, when the guide pin and milling cutter are on the same level, the LED lights on both sides of the machine brand will be green meanwhile. The brush motor rotates at 5000-rotation per minute.
- By pressing handle on the right side up and down, you can set the height at your will, then twist it clockwise to fix the height; If you need to adjust the height of the guide pin, you can twist the knob slightly on the left side.
- Both AC and DC can be used for power supply, with LED switch button, powerful, high-speed and low noise, this is the unique function for CSH002.
Why Choose CSH-002 Vertical Milling Key Cutting Machine:
- Ergonomic design, portable and ingenuity
- Lock blocks combined with multi-functional fixture, high quality and favorable price
- Support internal milling/external milling/punching keys, etc
- High strength all aluminum structure body
- High precision cross guide rail
- Highly sensitive and easy to control slide table
- LED electronic calibration
- AC and DC are workable,suitable for different power supply
- The main shaft and calibration shaft are made of high speed steel
CSH-002 Mini Key Machine Power Supply Mode:
1. 220V direct civil power supply
One end of the power supply is connected to a 220V civil socket
The other end of the power supply is connected to the DC port of the machine
2. Car cigarette lighter power supply
One end of the power supply is connected to the cigarette lighter socket
The other end of the power supply is connected to the DC port of the machine
3. Car battery power supply
Car battery power supply: red line is connected to the positive electrode, and the black line is connected to the negative electrode
The other end of the power supply is connected to the DC port of the machine
CSH-002 Mini Machine Parameters:
- Product name: CSH-002 Mini Vertical Key Cutting Machine
- Dimensions: 26*24*36CM
- weight: 12KG
- Working method: Manual
- Error scope: ≤0.02mm
- Operating temperature: 0-50℃
- Operating humidity: 10-90％
- Rated Voltage: AC110-220V / 12V DC
- Carriage: Straight line slide carriage
- Material: Aluminum alloyed casting
- Spindle moving distance: 30mm
- Moving distance in X-direction: 42mm
- Moving distance in Y-direction: 53mm
- Rotate speed: 5000RPM
- Power: 150W
- Motor Power: 100W
